Compatible with DTM DT Series 12-pin Connector Kit, 20AWG Solid Contacts Receptacle IP67 Waterproof Heavy Duty
ℹ
Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.
•▲Package Included: 1x Male housing, 1x Female housing, 1x Orange wedgelock, 1x Green wedgelock, 8x Male contact, 8x Female contact.
•▲Accepts contact size 20 (7.5 amps). Connectors show no damage when exposed to most fluids used in industrial applications
•▲Waterproof for properly wired and mated connections, immersion under 3 feet of water without loss of electronic qualities or leakage. Insulation Resistance of 1000 megohms minimum at 25° C
•▲Current leakage less than 2 milliamps at 1500 VAC
•▲Operating at temperatures from -55° C to +125° C continuous at rated current
